VELUX 970 x 970mm Flat Roof Skylight

I/N: 0820124
$362
Price correct as at Mon 11 Dec 2017 3:02:25pm
Add to Store Order
Products can be picked up or delivered. Your local store will contact you to confirm stock availability, delivery charges and organise payment.
Add to Cart
Confirm whether the customer will pick up their order or have it delivered. Contact the supplier to confirm stock availability. If applicable, please organise payment at this time.
Not all products available in all stores
Contact your nearest store for product information.

Product Description

The FCM Skylight is a cost effective way to provide natural daylight to buildings with flat roofs. Ideal as an alternative or to replace inefficient plastic domes, the laminated safety glass will not fade or discolour and has been tested for hail resistance.
Double glazing blocks approximately 75% of radiant heat, as well as approximately 99% of harmful UV rays.

  • Blocks approximately 75% radiant heat and approximately 99% harmful UV
  • Suitable for flat roofs (3-5° minimum pitch recommended to avoid water pooling on glass)
  • Bushfire rated to BAL 40 (0-60° pitch – consult VELUX)
  • Laminated safety pane as standard to meet AS1288
  • Tested for hail resistance

Product Details

Model Name
VELUX Flat Roof Skylight
Model Number
FCM 3434 0004AB
Material
Aluminium Curbmount, Insulated Glazing Unit
Product Dimensions (mm)
W:970 H:970 L:75
Package Dimensions (mm)
W:120 H:1067 L:1080
Frame Material
Aluminium curb mount Frame
Glazing Type
Laminated Double Glazed, Argon filled, low E coating, easy clean
Insect Screen
No
Maximum roof pitch (degrees)
60
Mounting type
Curb Mounted
Remote Control
No
Rotates for Cleaning
No
Severe weather ready
Yes
Skylight Mounting Type
Curb Mounted
U-factor (Btu/hr ft^2 F)
3.3
UV protection (%)
99
Flashing Included
No
Hardware Included
No

Product Downloads

Brochure
Download
Installation Guide
Download
Specifications
Download
Warranty
Download

Additional Info

Warranty Info

10 Year Warranty
*See VELUX warranty for details

Installation Info

See supporting files

Delivery Info

Refer to page 14 of our brochure - see supporting files
