Product Description

The FCM Skylight is a cost effective way to provide natural daylight to buildings with flat roofs. Ideal as an alternative or to replace inefficient plastic domes, the laminated safety glass will not fade or discolour and has been tested for hail resistance.

Double glazing blocks approximately 70% of radiant heat, as well as approximately 99% of harmful UV rays.

  • Blocks approximately 70% radiant heat and approximately 99% harmful UV
  • Suitable for flat roofs (3-5° minimum pitch recommended to avoid water pooling on glass)
  • Bushfire rated to BAL 40 (0-60° pitch – consult VELUX)
  • Laminated safety pane as standard to meet AS1288
  • Tested for hail resistance

Product Details

Model Name
VELUX Flat Roof Skylight
Model Number
FCM 2222 0004AB
Aluminium Curbmount, Insulated Glazing Unit
Ironstone Grey
Product Dimensions (mm)
W:665 H:665 L:75
Package Dimensions (mm)
W:120 H:749 L:762
Frame Material
Aluminium curb mount Frame
Glazing Type
Laminated Double Glazed, Argon filled, low E coating, easy clean
Maximum roof pitch (degrees)
Mounting type
Curb Mounted
Severe weather ready
Skylight Mounting Type
Curb Mounted
U-factor (Btu/hr ft^2 F)
UV protection (%)
Flashing Included
Hardware Included

Product Downloads

Installation Guide

Additional Info

Warranty Info

10 Year Warranty
*See VELUX warranty for details

Installation Info

See Product Downloads

Delivery Info

Refer to page 14 of our brochure - see Product Downloads
