VELUX 550 x 980mm Dual-Action Roof Window

I/N: 0820118
Price correct as at Tue 20 Mar 2018 9:42:23am
Add to Store Order
Products can be picked up or delivered. Your local store will contact you to confirm stock availability, delivery charges and organise payment.
Add to Cart
Confirm whether the customer will pick up their order or have it delivered. Contact the supplier to confirm stock availability. If applicable, please organise payment at this time.
Not all products available in all stores
Contact your nearest store for product information.

Special Order

Thousands more Special Orders products available to buy online or in-store. Find out more

Product Description

Beautifully engineered for a lifetime of use, the VELUX GPL roof window is ideal for in-reach attic solutions.
The dual action hinge system offers choice of function, allowing for centre-pivot motion or top hung operation. With a choice of blinds available to add that finishing touch, the GPL roof window is the perfect option for any attic space.

  • Approx 70% radiant heat block and approximately 95% harmful UV reduction
  • Ventilation flap provides passive ventilation while keeping the elements out
  • Bushfire rated to BAL 40 (18-55° pitch, requires custom flashing and additional mesh screening - consult VELUX)
  • Laminated safety pane as standard to meet AS1288
  • Sash rotates 180 degrees allowing the outer pane to be cleaned from inside

Product Details

Model Name
VELUX Dual Action Roof Window / Skylight
Model Number
GPL CK04 2076G
Timber frame, aluminium cappings, insulated glazing unit
Product Dimensions (mm)
W:550 H:980 L:165
Package Dimensions (mm)
W:171 H:579 L:1048
Frame Material
Nordic Pine
Glazing Type
Argon filled double glazing with low E coating and laminated safety pane
Insect Screen
Maximum roof pitch (degrees)
Minimum roof pitch (degrees)
Mounting type
Brackets mount to battons
Manual in reach centre-pivot and top hung operation
Rotates for Cleaning
Severe weather ready
Skylight Mounting Type
Brackets mount to battons
Telescoping control rod
U-factor (Btu/hr ft^2 F)
UV protection (%)
Flashing Included
Hardware Included

Product Downloads

Installation Guide

Additional Info

Warranty Info

10 Year Warranty, 3 Year Warranty on Hinges & Handles
*See VELUX warranty for details

Installation Info

See Product Downloads

Delivery Info

Refer to page 14 of our brochure - see Product Downloads
