12V Wireless 3000lbs / 1361KG Electric Boat Trailer Winch & 4WD Winch 12V WIRELESS STEEL CABLE ATV ELECTRIC WINCH 3000LBS/1361KGS. This X Bull I-MAX  ATV 3000lbs winch is made to be a highest performance and reliable product. It provides strong power to recover your vehicle when it is stuck under various circumstances in the off-road adventure. Wireless Remote Controller Safety Design!  In order to avoid misoperation, the wireless remote controller needs to be pressed the power switch and held more than 3 seconds to start. Line Speed and motor current (first Layer) Line pull Lbs 0 1000 2000 3000 Kgs 0 454 907 1360 Line Speed FPM 9.5 6.6 3.6 2.3 MPM 2.8 2.0 1.1 0.7 Motor Current Amps 12 60 90 150  Line Pull and cable capacity Layer of cable 1 2 3 4 5 Rated line pull per layer Lbs 3000 2320 1890 1590 1380 Kgs 1360 1052 858 720 620  Cable capacity per layer Ft 4.9 11.5 19.3 28.5 32 M 1.5 3.5 5.9 8.7 10 3000lbs Electric Winch Features Three-stage Planetary Gear System Super Big Power Power In & Power Out Motor for Positive Load Control Automatic Load-Holding Braker for Maximum Safely High Tensile Steel Cable Free Spooling Clutch for Fast Wire Rope Pay-out Heavy Duty Sealed Contactor Quick-Attach Mounting Plate Wire/Wireless Remote Control Model for Easy Operation 4-Way Roller Fairlead Quiet and Efficient Waterproof and Corrosion Resistant 3000lbs Note: Images for display purposes only. may differ slightly. Electric Winch Specifications Condition: Brand New Rated Line Pull: 3000LBS/1361KGS Single Line Motor: DC 12V - 1.2HP/0.9KW Output Gear Train: 3 Stage Planetary Gear Ratio: 150:1 Clutch: Sliding Ring Gear Braking Action: Automatic in the Drum Fairlead: 4-Way Roller Fairlead Wire Rope: 4.5mm × 12.5m Drum Size: 31.75mm × 72mm Dimensions: 300mm × 104mm × 100mm Net Weight: 8.5kg
