- Compact 2u design
- 1500va rack-mount ups with avr
- Smartconnect and graphic lcd
- 3% ieee surge let-through: zero clamping response time: meets ul 1449 physical • maximum height: 89, 8
- 9 cm • maximum width: 432, 43
DESCRIPTION
Output• Output power capacity:900 Watts / 1.5 kVA• Max Configurable Power (Watts):900 Watts / 1.5 kVA• Nominal Output Voltage: 230V• Output Voltage Distortion: Less than 5% at full load• Output Frequency (sync to mains): 57 - 63 Hz for 60 Hz nominal• Topology: Line Interactive• Waveform type: Sine wave• Output Connections: (8) IEC 320 C13 (Battery Backup)• Transfer Time: 2ms typicalInput• Nominal Input Voltage: 230V• Input frequency: 50/60 Hz +/- 3 Hz (auto sensing)• Input Connections: IEC-320 C14• Input voltage range for main operations: 180 - 287 V• Input voltage adjustable range for mains operation: 170 - 300 V• Number of Power Cords: 1• Other Input Voltages: 220, 240Batteries & Runtime• Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof• Typical recharge time: 3 hour(s)• Replacement Battery: APCRBC132• RBC Quantity: 1• Battery Volt-Amp-Hour Capacity: 260• Runtime: View Runtime Graph View Runtime ChartCommunications & Management• Interface Port(s): USB• Control panel: Multi-function LCD status and control console• Audible Alarm: Alarm when on battery: distinctive low battery alarm: configurable delays• Emergency Power Off (EPO): --Surge Protection and Filtering• Surge energy rating: 459 Joules• Filtering: Full time multi-pole noise filtering: 0.3% IEEE surge let-through: zero clamping response time: meets UL 1449Physical• Maximum Height: 89, 8.9 cm• Maximum Width: 432, 43.2 cm• Maximum Depth: 457, 45.7 cm• Rack Height: 2 U• Net Weight: 28.64 kg• Color: BlackOperating Temperature• Operating Environment: 0 - 40 °C• Operating Relative Humidity: 0 - 95 %• Operating Elevation: 0-3000 meters• Storage Temperature: -15 - 45 °C• Storage Relative Humidity: 0 - 95 %• Storage Elevation: 0-15000 meters• Audibl
